InstruCalc 8.1Calculates the
size of Control Valves – Flow Elements – Relief Devices – Fluid Properties –
Pipe Pressure Loss – Liquid Waterhammer
Size more
than 50 different instruments with this easy-to-use and accurate sizing
program.
Calculates
the sizes of control valves, flow elements, and relief devices; produces
data sheets for calculated items; and prepares instrument summaries and
uses data sheets as a database for generating reports.
The
Control valve and Flow element modules now will calculate, display and
print graphs of your calculations.
AllowsYOUto select any set of
engineering units, including your own customized set. Units can be
mixed, matched and changed in the middle of a calculation.
Consists
of more the 74 routines divided into four main sections:
Control Valves • Flow Elements
• Relief Devices • Process Data
Calculates
process data at flow conditions for 54 fluids in either mixtures or
single components
and 66 gases in either mixtures or single components. Files can be
updated with additional users'
fluids and gases.
Calculates
the orifice size, flowrate or differential
range, which enables the user to select the flowrate
with optimum accuracy. It provides the recommended size and corrects the
orifice size accordingly.
Process
data can be converted individually or jointly with a simple "click
of the mouse."
InstruCalc 8.1is still the only sizing programs you need
to consider!
WHAT'S NEW IN INSTRUCALC VERSION 8.1:
1.
Engineering Standard upgrades Latest CV ISO Standard ANSI/ISA
75.01.01-2007 Pressure Relief Devices Program
follows API 520 2009
2.
Engineering Improvements Technique for showing cavitation in restriction orifices and venturi meters (Flow Elements) Expanded vortex meter sizes
available – up to size 36 (Flow Elements) Incorporation of Z-factor in
gas-flow for sizing Flow Elements AGA8 option for Natural Gas in Flow
Elements Added option to specify outlet
pressure of orifice Flow Element. Added Text box at the bottom of the
calculation for comments such as exit angle of venture meters PRV Program provides option to
calculate flow rate for a known size RV. Clarify status to show more clearly
flashing, cavitation and choking of control
valves. Outlet of control valves - flow
velocity at outlet flange Allow for Density input instead of
Specific Gravity in all Programs Allow absoluteand gauge units for all pressure inputs
3.
Operational Improvements Program
runs in Windows 7, 64 bit.
Rearrange appearance of program – basic
form set-up and day to day options – removed
them and clarified their use.
Excel Import/Export for process data
Database Print manager with options to
print all of the database stored data and all the
calculations or
any combination of them.
Contact Gulf Publishing Company Software for eligible upgrade pricing
from Instrucalcversion 6.X and version 7.X
Software
Search through more than40 desktop applicationsdesigned for the engineer
by engineers to make your day-to-day job easier. Many of our software
products are available as demo versions. A list of these can be found under
Free Trials/Demos.
For more information, contactsvb@GulfPub.comor +1 (713) 520-4301.
